LAYOUT OF COLUMNS FOR UCD – XENON LAMPS
- The height of the pole, 11m ~ 12m, 2 lanes + Sidewalk, distance between columns = 40 meter, lamp = 250W.
- Height of columns 11m ~ 12m pole, 3 ~ 4 lanes on one side, distance = 40m, lamp = 250W.
- Pole height of 11m ~ 12m, 2 lanes roundtrip, distance of columns = 40 meter, lamp = 150W.
- Pole height of 9m ~ 10m, 2 lanes round-trip, distance of columns = 30m ~ 35m, lamp = 150W & 100W lamps.
- Height of columns 9m ~ 10m, 2 lanes roundtrip, distance of columns = 30m ~ 35m, lamp = 100W & 150W.
- Pole height of 7m ~ 9m, 2 lanes roundtrip, distance of 30m ~ 35m poles, lamp = 70W, & 100W.
- GD-Gardens & Boulevards, height 4.5m ~ 5.5m, 20m distance of columns = ~ 25m ~ 30m, lamps = 70, 100 & 150W.
- Note: In all cases the loss of lighting between columns is <0.05 Count / meter insignificant, = ~ 700nano / meter.
- Operation on the European System Voltage 220 ~ 240V, UCD-180 Volt Xenon = ~ 265 Volt. (135V ~ 295V UCD OKAY).
